Calculating the special requirements of orifice flowmeter,Xi'an Huaheng Instrument will introduce to you:the orifice flowmeter designed,manufactured and calibrated according to the national standard does not need real-flow calibration,has high accuracy,simple structure and low manufacturing cost,but the pressure loss is the largest in all standard throttling devices,and is not suitable for situations requiring small pressure loss.The standard orifice plate is widely used in petroleum and chemical industry.Industry,metallurgy,electricity and other industries.





　　生產節流裝置廠商都知道，在對孔板流量計和V錐流量計等節流裝置根據現場參數計算開孔直徑的時候，會涉及到這么一個問題，就是差壓變送器的最大差壓值如何選取的問題？差壓值如何選取，該選多大的？和很多因素有關，比如：不確定度，前后直管段等，所以說在計算孔板流量計和V錐流量計的開孔直徑時，千萬不能盲目的選取大的差壓，而要綜合考慮一些相關因素。



　　Manufacturers of throttling devices know that when calculating the diameter of orifice according to field parameters,such as orifice plate flowmeter and V-cone flowmeter,it will involve such a problem as how to select the maximum differential pressure of differential pressure transmitter.How to choose the differential pressure value and how large should it be?It is related to many factors,such as uncertainty,front and back straight pipe sections,etc.Therefore,when calculating the diameter of orifice plate flowmeter and V-cone flowmeter,we must not blindly select large differential pressure,but consider some related factors synthetically.



　　1、以上基本介紹的是選取差壓大的優點，不過發展到了一定程度，必將相對的帶來一些弊端。熟悉孔板流量計和V錐流量計加工工藝的人應該知道，當差壓選取過大的時候，那么導致的直接后果就是開孔變的很小，那么相對的就是壓力損失也很大，孔板流量計本來壓力損失就很大，如果再加上這個的話，那么對整個工藝系統來說，由于這個壓力損失而造成的費用是相當可觀的；V錐流量計相比起來，稍微適中點。



　　1.The above basic introduction is to select the advantages of high differential pressure,but to a certain extent,it will bring some relative disadvantages.People familiar with orifice flowmeter and V-cone flowmeter processing technology should know that when the differential pressure is too large,the direct consequence is that the opening becomes very small,then the relative pressure loss is also very large,orifice flowmeter original pressure loss is very large,if this is added,then for the entire process system,the pressure loss caused by this pressure loss.The cost is considerable;the V-cone flowmeter is slightly moderate in comparison.



　　2、差壓值大時，β值變小，推薦使用的最小雷諾數較小。這樣的話，使得實際雷諾數有可能遠大于推薦使用的雷諾數，于是流量系數趨于穩定，測量精度也就提高。



　　2.When the differential pressure is large,the beta value decreases and the minimum Reynolds number recommended is small.In this way,the actual Reynolds number may be much larger than the recommended Reynolds number,so the flow coefficient tends to be stable and the measurement accuracy will be improved.



　　3、而對于差壓變送器來說，差壓大的比差壓小的更加穩定。



　　3.For the differential pressure transmitter,the higher the differential pressure is,the more stable the lower the differential pressure is.



　　4、差壓值大時，所需要的最小直管段可以短些。



　　4.When the differential pressure is large,the minimum straight pipe section needed can be shorter.



　　針對這個特點，對于一體化孔板流量計說，考慮各方面經濟的因素，應該選取差壓最大的那個開孔值；而V錐流量計則相對好點了，對于現場流體是牛頓流體的話，本身V錐流量計的直管段要求就比較低，即使短些的話，相比而言的話，也不存在了。



　　In view of this characteristic,for the integrated orifice plate flowmeter,considering various economic factors,we should choose the opening value with the greatest differential pressure;for the V-cone flowmeter,it is relatively better.For the field fluid is Newtonian fluid,the straight pipe section of the V-cone flowmeter itself is relatively low,even if it is shorter,it does not exist in comparison.
